Position：Web Index >> Product >> Circular Connectors >> Y4 series CIRCULAR CONNECTOR
Product
Name：Y4 series CIRCULAR CONNECTOR
Model：Y4 series
Price：
Features：Y4 series circular connectors have the features of small size,light weight,convenient application with threaded-coupling connection.They are widely used for the electrical connection between electrical equipments and instruments.there are flange style and cable style.
Product description：
| Technical characteristics | |
| Temperature | -55℃～+125℃ |
| Relative humidity | 40℃，at 95% |
| Vibration | 10-2000HZ,196m/s2 |
| Impact | 980m/s2 |
| Leak Lightness | 0.2Mpa |
| Endurance | 500 cycles |
